Home>X ray tubes

X ray tubes

Model Max Output introduction
Voltage(KV) Power(W)
Contact Way
Address:Rm.2-20901,Tsinghua Science Park,Technology Road 65,High-tech District ,Xi'an,Shaanxi Province China 710075
Tel:86-029-33693480
86-029-33693481
Fax:86-029-33693482
E-mail:sales@wismanhv.com

50KV

50W

1.Max anode current: 1.0 ma

2.Max anode voltage: 50 kv

3.Maximum power: 50 w continuous

4.Nominal filament voltage: 2.0 v @ 50 kv, 1 ma

5.Max filament current: 1.7 a

6.Stability: 0.2% over 4 hours

7.Focal spot size (nominal*): 110 μm

8.Anode material: w, mo, rh (other materials available)

9.Be window thickness: 125μm (75 μm, 250μm options available)

10.Approximate weight: 4 lbs (1816 g)

11.Cooling method: forced air @ 150 cfm

12.Cone angle: 25
